In industries such as powder metallurgy, electronic semiconductors and aerospace, argon compressors are the core equipment for ensuring gas circulation pressurization.In the face of complex industrial sites, the equipment must have extremely high process adaptability.Based on a deep insight into the diverse demands of the market, Greatall Cheng'en has built a "product matrix" covering all operating conditions, precisely matching various process requirements from micro-positive pressure to medium-pressure intake and from medium and small flow to large flow production lines through the three models of 2V, M and Z.
1. Technical parameters of core models
The entire series of models adopt reciprocating piston, cylinder oil-free lubrication, packing argon protection and multi-stage compression design, ensuring argon purity while meeting differentiated process parameters through different structural designs:
2V type: Flexible pressurization solution for medium and small flow rates
Key parameters: Displacement 600-800Nm³/h, compatible with slightly positive pressure intake, exhaust pressure 6.2-9.5MPa
Applicable scenarios: The compact design is perfect for fine-grained production workshops with limited space.
M type: A robust support solution for high-flow production lines
Key parameters: 800-2400Nm³/h displacement, supporting slightly positive pressure intake and high pressure output of 6.2-9.5MPa.
Applicable scenarios: Primarily for high-flow continuous pressurization, it is the preferred choice for high-load conditions such as large-scale powder metallurgy production lines.
Z type: An energy efficiency optimization solution for re-pressurizing low-pressure argon gas
Parameter core: Designed for low-pressure intake at 0.6 to 1.0MPa, displacement 1000 to 1500Nm³/h.
Application scenarios: Lightweight skid-mounted design for applications with screw pressurization at the front end.
2. Quick selection logic: Conditions determine configuration
In actual application scenarios, precise decisions can be made through the following two dimensions when the end-use pressure of argon gas is 6.2 to 9.5MPa:
Slightly positive pressure intake: 2V type for medium and small flow rates (600-800Nm³/h) and M type for large flow rates (800-2400Nm³/h).
Low-pressure intake (0.6-1.0Mpa) : For small flow rates (below 200Nm³/h), choose small Z; for medium and small flow rates (200-1000Nm³/h), choose V; for medium and large flow rates (1000-1500Nm³/h), choose large Z; for large flow rates (1200-2400Nm³/h), choose double V.
III、 Technical advantages: Pure, stable and flexible
Pure and oil-free: With a fully oil-free cylinder lubrication structure and argon-filled packing protection design, it prevents oil from entering the compression chamber from the source and ensures high-purity argon recovery.
High pressure stability: Stable output in the 6.2-9.5MPa pressure range, supporting industrial-grade 24/7 continuous operation.
Rapid deployment: Available in both fixed and highly integrated skid-mounted forms, the skid-mounted form has high integration and enables rapid production.
The three models of argon compressors are precisely positioned to cover the mainstream conditions in powder metallurgy, additive manufacturing and other fields.For more detailed parameters or customized solutions, please contact our technical team for professional support.
